STANDARD RESISTOR VALUES

Resistor

STANDARD RESISTOR VALUES

STANDARD RESISTOR VALUES
MOVE THE DECIMAL POINT FOR ANY VALUE 1%, 5%, 10% AND 20% ARE LISTED.
       1% INCREMENTS        . 5% 10% 20%

10.0     10.2     10.5      10.7   10.0 10.0 10.0
11.0      11.3    11.5     11.8    11.0
12.1     12.4     12.7     13.0    12.0 12.0
13.3     13.7     14.0     14.3    13.0
14.7     15.0     15.4     15.8    15.0 15.0 15.0
16.2     16.5     16.9     17.4    16.0
17.8     18.2     18.7     19.1    18.0 18.0
19.6     20.0     20.5     21.0    20.0
21.5     22.1     22.6     23.2    22.0 22.0 22.0
23.7     24.3     24.9     25.5    24.0
26.1     26.7    27.4     28.0     27.0 27.0
28.7     29.4     30.1     30.9    30.0
31.6     32.4     33.2     34.0    33.0 33.0 33.0
34.8     35.7     36.5     37.4    36.0
38.3     39.2     40.2     41.2    39.0 39.0
42.2     43.2     44.2     45.3    43.0
46.4     47.5     48.7     49.9    47.0 47.0 47.0
51.1     52.3     53.6     54.9    51.0
56.2     57.6     59.0     60.4     56.0 56.0
61.9     63.4     64.9     66.5       62.0
68.1     69.8    71.5      73.2     68.0 68.0 68.0
75.0     76.8     78.7     80.6    75.0
82.5     84.5     86.6     88.7    82.0 82.0
90.9     93.1     95.3     97.6    91.0
