ATU/ARU-2HD HD VIDEO REMOTE CONTROL RELAY TRANSMITTER

$844.00

These products transmit and receive relay control contact closures encoded on any video signal such as AHD, HD-TVI, HD-CVI, PAL, and NTSC Video over cable, twisted pair wire, or wireless system. You can send your relay control signals anywhere a video signal is being used, including optical laser transmission and wireless transmission of video. Relay control signals will be carried over any distance that the video signal can go. Control and tele-metering relay contact closures are encoded onto the video signal by the ATU-2HD unit and decoded in the ARU-2HD unit with relay outputs.

9 in stock (can be backordered)

Description



Download Specifications <
Click here to download the manual in Word 6.0 format. Download Manual
Click here to download the manual in Word 6.0 format. Download “How to Add Remote Control to HD Video” Article
Click here to download the manual in Word 6.0 format. Download “How to Add control relays to HD Video” Article

Part Number: ATU/ARU-2HD
Title: HD VIDEO REMOTE CONTROL RELAY TRANSMITTER / RECEIVER SET
Category: HD Video Products
Industry: CCTV/Security

Description:

These products transmit and receive relay control contact closures encoded on any video signal such as AHD, HD-TVI, HD-CVI, PAL, and CVBS/NTSC Video over cable, twisted pair wire, or wireless system. You can send your relay control signals anywhere a video signal is being used, including optical laser transmission and wireless transmission of video. Relay control signals will be carried over any distance that the video signal can go. Control and tele-metering relay contact closures are encoded onto the video signal by the ATU-2HD unit and decoded in the ARU-2HD unit with relay outputs.



Each ATU-2HD/ARU-2HD will send two contact control relay signals in the vertical interval of the video without interfering with the picture. The units are field programmable to insert the signal on any of 8 lines in the vertical interval so more than one system can be used on the same video signal by selecting different lines for each system. Up to four systems can be used to provide a maximum of 8 control relays. The video format is field programmable for AHD, HD-TVI, HD-CVI, PAL and NTSC/CVBS video with the on board DIP switch.

One channel of the ATU-2HD / ARU-2HD can be used as a system alarm that will operate upon loss of power to either terminal, loss of the video signal or loss of transmission path, a cable cut, or wireless failure. The unit has a video loop through so in the event of power failure, the video through-put is not interrupted. Contact closures to the ATU-2HD input will be repeated as contact relay closures at the ARU-2HD output.



The system is housed in an ABS enclosure that has a UL flame rating of 94-VO and is powered by 12 Volt AC or DC power transformers (12 Volt DC power cubes are supplied with the units). The current draw is low allowing the units to be connected to the same power supply as the camera. Both the transmitter and the receiver have power/video on LED indicators for easy set-up and the ARU-2HD has two LEDs to monitor the relay outputs.

If this product page shows “out of stock” the product is in production and can be purchased with a lead time of 1-2 weeks or less depending on quantity. To place an order for this product call 1-800-235-6960 and ask for the sales department. Or E-Mail your order to fmsystemsinc@sbcglobal.net. Most orders ship within a few days.

ATU-2HD RELAY TRANSMITTING UNIT



CONTACT INPUT                                                   SPECIFICATIONS

Channels                                                                     2

Connector                                                                   4 Pos. Screw Terminal

Alarm Sense                                                                Contact closure (Loop)

Maximum Loop Resistance                                         2K ohm



VIDEO INPUT

Standard                                                                      TVI 720p 25/30fps, TVI 1080p 25/30fps, TVI 4MP15/25/30fps, TVI 5MP 12.5/20fps

CVI 720p 25/30fps, CVI4MP 25/30fps, AHD 720p 25/30fps, AHD 1080p 25/30fps

AHD 4MP 15/25/30fps, AHD 5MP 12.5/20fps, PAL 625L 50Hz, CVBS 525L 60Hz

Impedance                                                                  Hi-Z Video loop through

Connectors                                                                  2 BNC (female) Standard

Line Selection (field agile)                                        8 Lines (3-4, 7-8, 11-12, 15-16)



MECHANICAL

Size                                                                             5.50″L X 3.3″W X 2.0″D

Power                                                                          12 Volts AC/DC 40 mA

Power cube                                                                 12 Volts DC (included)

ARU-2 ALARM RECEIVING UNIT



ALARM OUTPUT                                                   SPECIFICATION

Channels                                                                     2

Connector                                                                   4 Pos. Screw Terminal

Alarm Report                                                              C Form Relay 1 Amp (Selectable)



VIDEO INPUT

Standard                                                                     TVI 720p 25/30fps, TVI 1080p 25/30fps, TVI 4MP15/25/30fps, TVI 5MP 12.5/20fps
CVI 720p 25/30fps, CVI4MP 25/30fps, AHD 720p 25/30fps, AHD 1080p 25/30fps
AHD 4MP 15/25/30fps, AHD 5MP 12.5/20fps, PAL 625L 50Hz, CVBS 525L 60Hz

Impedance                                                                  Hi-Z Video loop through

Connector                                                                   2 BNC (female) Standard

Line Selection                                                             8 Lines (3-4, 7-8, 11-12, 15-16)



MECHANICAL

Size                                                                             5.50″L x 3.3″W x 2.0″D

Power                                                                          12 Volts AC/DC    40 mA

Power Cube                                                                12 Volts DC (included)

Additional information

Weight 5 lbs
Dimensions 12 × 12 × 7 in
